In the previous article in this series on the REMCOS implant, we shared information about execution, persistence, and defense evasion mechanisms. Continuing this series we’ll cover the second half of its execution flow and you’ll learn more about REMCOS recording capabilities and communication with its C2.

Starting watchdog

If the enable_watchdog_flag (index 0x32) is enabled, the REMCOS will activate its watchdog feature.

0x40F24F Starting watchdog feature if enabled in the configuration
0x40F24F Starting watchdog feature if enabled in the configuration

This feature involves the malware launching a new process, injecting itself into it, and monitoring the main process. The goal of the watchdog is to restart the main process in case it gets terminated. The main process can also restart the watchdog if it gets terminated.

Console message indicating activation of watchdog module
Console message indicating activation of watchdog module

The target binary for watchdog injection is selected from a hardcoded list, choosing the first binary for which the process creation and injection are successful:

  • svchost.exe
  • rmclient.exe
  • fsutil.exe

0x4122C5 Watchdog target process selection
0x4122C5 Watchdog target process selection

In this example, the watchdog process is svchost.exe.

svchost.exe watchdog process
svchost.exe watchdog process

The registry value HKCU/SOFTWARE/{MUTEX}/WD is created before starting the watchdog process and contains the main process PID.

The main process PID is saved in the WD registry key
The main process PID is saved in the WD registry key

Once REMCOS is running in the watchdog process, it takes a "special" execution path by verifying if the WD value exists in the malware registry key. If it does, the value is deleted, and the monitoring procedure function is invoked.

0x40EB54 Watchdog execution path when WD registry value exists
0x40EB54 Watchdog execution path when WD registry value exists

It is worth noting that the watchdog process has a special mutex to differentiate it from the main process mutex. This mutex string is derived from the configuration (index 0xE) and appended with -W.

Mutex field in the configuration
Mutex field in the configuration

Comparison between main process and watchdog process mutexes
Comparison between main process and watchdog process mutexes

When the main process is terminated, the watchdog detects it and restarts it using the ShellExecuteW API with the path to the malware binary retrieved from the HKCU/SOFTWARE/{mutex}/exepath registry key

Console message indicating process restart by watchdog
Console message indicating process restart by watchdog

Starting recording threads

Keylogging thread

The offline keylogger has two modes of operation:

  1. Keylog everything
  2. Enable keylogging when specific windows are in the foreground

When the keylogger_mode (index 0xF) field is set to 1 or 2 in the configuration, REMCOS activates its "Offline Keylogger" capability.

Keylogging is accomplished using the SetWindowsHookExA API with the WH_KEYBOARD_LL constant.

0x40A2B8 REMCOS setting up keyboard event hook using SetWindowsHookExA
0x40A2B8 REMCOS setting up keyboard event hook using SetWindowsHookExA

The file where the keylogging data is stored is built using the following configuration fields:

  • keylogger_root_directory (index 0x31)
  • keylogger_parent_directory (index 0x10)
  • keylogger_filename (index 0x11)

The keylogger file path is {keylogger_root_directory}/{keylogger_parent_directory}/{keylogger_filename}. In this case, it will be %APPDATA%/keylogger.dat.

Keylogging data file keylogger.dat
Keylogging data file keylogger.dat

Keylogging data content
Keylogging data content

The keylogger file can be encrypted by enabling the enable_keylogger_file_encryption_flag (index 0x12) flag in the configuration. It will be encrypted using the RC4 algorithm and the configuration key.

0x40A7FC Decrypting, appending, and re-encrypting the keylogging data file
0x40A7FC Decrypting, appending, and re-encrypting the keylogging data file

The file can also be made super hidden by enabling the enable_keylogger_file_hiding_flag (index 0x13) flag in the configuration.

When using the second keylogging mode, you need to set the keylogger_specific_window_names (index 0x2A) field with strings that will be searched in the current foreground window title every 5 seconds.

0x40A109 Keylogging mode choice
0x40A109 Keylogging mode choice

Upon a match, keylogging begins. Subsequently, the current foreground window is checked every second to stop the keylogger if the title no longer contains the specified strings.

Monitoring foreground window for keylogging activation
Monitoring foreground window for keylogging activation

Screen recording threads

When the enable_screenshot_flag (index 0x14) is enabled in the configuration, REMCOS will activate its screen recording capability.

0x40F0B3 Starting screen recording capability when enabled in configuration
0x40F0B3 Starting screen recording capability when enabled in configuration

To take a screenshot, REMCOS utilizes the CreateCompatibleBitmap and the BitBlt Windows APIs. If the enable_screenshot_mouse_drawing_flag (index 0x35) flag is enabled, the mouse is also drawn on the bitmap using the GetCursorInfo, GetIconInfo, and the DrawIcon API.

0x418E76 Taking screenshot 1/2
0x418E76 Taking screenshot 1/2

0x418E76 Taking screenshot 2/2
0x418E76 Taking screenshot 2/2

The path to the folder where the screenshots are stored is constructed using the following configuration:

  • screenshot_parent_directory (index 0x19)
  • screenshot_folder (index 0x1A)

The final path is {screenshot_parent_directory}/{screenshot_folder}.

REMCOS utilizes the screenshot_interval_in_minutes (index 0x15) field to capture a screenshot every X minutes and save it to disk using the following format string: time_%04i%02i%02i_%02i%02i%02i.

Location where screenshots are saved
Location where screenshots are saved

Similarly to keylogging data, when the enable_screenshot_encryption_flag (index 0x1B) is enabled, the screenshots are saved encrypted using the RC4 encryption algorithm and the configuration key.

At the top, REMCOS has a similar "specific window" feature for its screen recording as its keylogging capability. When the enable_screenshot_specific_window_names_flag (index 0x16) is set, a second screen recording thread is initiated.

0x40F108 Starting specific window screen recording capability when enabled in configuration
0x40F108 Starting specific window screen recording capability when enabled in configuration

This time, it utilizes the screenshot_specific_window_names (index 0x17) list of strings to capture a screenshot when the foreground window title contains one of the specified strings. Screenshots are taken every X seconds, as specified by the screenshot_specific_window_names_interval_in_seconds (index 0x18) field.

In this case, the screenshots are saved on the disk using a different format string: wnd_%04i%02i%02i_%02i%02i%02i. Below is an example using ["notepad"] as the list of specific window names and setting the Notepad process window in the foreground.

Screenshot triggered when Notepad window is in the foreground
Screenshot triggered when Notepad window is in the foreground

Audio recording thread

When the enable_audio_recording_flag (index 0x23) is enabled, REMCOS initiates its audio recording capability.

0x40F159 Starting audio recording capability when enabled in configuration
0x40F159 Starting audio recording capability when enabled in configuration

The recording is conducted using the Windows Wave* API. The duration of the recording is specified in minutes by the audio_recording_duration_in_minutes (0x24) configuration field.

0x401BE9 Initialization of audio recording
0x401BE9 Initialization of audio recording

After recording for X minutes, the recording file is saved, and a new recording begins. REMCOS uses the following configuration fields to construct the recording folder path:

  • audio_record_parent_directory (index 0x25)
  • audio_record_folder (index 0x26)

The final path is {audio_record_parent_directory}/{audio_record_folder}. In this case, it will be C:\MicRecords. Recordings are saved to disk using the following format: %Y-%m-%d %H.%M.wav.

Audio recording folder
Audio recording folder

Communication with the C2

After initialization, REMCOS initiates communication with its C2. It attempts to connect to each domain in its c2_list (index 0x0) until one responds.

According to previous research, communication can be encrypted using TLS if enabled for a specific C2. In such cases, the TLS engine will utilize the tls_raw_certificate (index 0x36), tls_key (index 0x37), and tls_raw_peer_certificate (index 0x38) configuration fields to establish the TLS tunnel.

It's important to note that in this scenario, only one peer certificate can be provided for multiple TLS-enabled C2 domains. As a result, it may be possible to identify other C2s using the same certificate.

Once connected we received our first packet:

Hello packet from REMCOS
Hello packet from REMCOS

As described in depth by Fortinet, the protocol hasn't changed, and all packets follow the same structure:

  • (orange)magic_number: \x24\x04\xff\x00
  • (red)data_size: \x40\x03\x00\x00
  • (green)command_id (number): \0x4b\x00\x00\x00
  • (blue)data fields separated by |\x1e\x1e\1f|

After receiving the first packet from the malware, we can send our own command using the following functions.

MAGIC = 0xFF0424
SEPARATOR = b"\x1e\x1e\x1f|"


def build_command_packet(command_id: int, command_data: bytes) -> bytes:
	return build_packet(command_id.to_bytes(4, byteorder="little") + command_data)


def build_packet(data: bytes) -> bytes:
	packet = MAGIC.to_bytes(4, byteorder="little")
	packet += len(data).to_bytes(4, byteorder="little")
	packet += data
	return packet

Here we are going to change the title of a Notepad window using the command 0x94, passing as parameters its window handle (329064) and the text of our choice.

def main() -> None:
	server_0 = nclib.TCPServer(("192.168.204.1", 8080))

	for client in server_0:
    	print(client.recv_all(5))

    	client.send(build_command_packet(
            			0x94,
            			b"329064" + SEPARATOR + "AM_I_A_JOKE_TO_YOU?".encode("utf-16-le")))

REMCOS executed the command, changing the Notepad window text
REMCOS executed the command, changing the Notepad window text

That’s the end of the second article. The third part will cover REMCOS' configuration and its C2 commands.
