LOOKUP JOIN

edit

LOOKUP JOIN

edit

The ES|QL LOOKUP join processing command combines data from your ES|QL query results table with matching records from a specified lookup index. It adds fields from the lookup index as new columns to your results table based on matching values in the join field.

Teams often have data scattered across multiple indices – like logs, IPs, user IDs, hosts, employees etc. Without a direct way to enrich or correlate each event with reference data, root-cause analysis, security checks, and operational insights become time-consuming.

For example, you can use LOOKUP JOIN to:

  • Retrieve environment or ownership details for each host to correlate your metrics data.
  • Quickly see if any source IPs match known malicious addresses.
  • Tag logs with the owning team or escalation info for faster triage and incident response.

LOOKUP join is similar to ENRICH in the fact that they both help you join data together. You should use LOOKUP JOIN when:

  • Your enrichment data changes frequently
  • You want to avoid index-time processing
  • You want SQL-like behavior, so that multiple matches result in multiple rows
  • You need to match on any field in a lookup index
  • You use document or field level security
  • You want to restrict users to use only specific lookup indices
  • You do not need to match using ranges or spatial relations

How the LOOKUP JOIN command works

edit

The LOOKUP JOIN command adds new columns to a table, with data from Elasticsearch indices.

esql lookup join
lookup_index
The name of the lookup index. This must be a specific index name - wildcards, aliases, and remote cluster references are not supported.
field_name
The field to join on. This field must exist in both your current query results and in the lookup index. If the field contains multi-valued entries, those entries will not match anything (the added fields will contain null for those rows).

Example

edit

LOOKUP JOIN has left-join behavior. If no rows match in the lookup index, LOOKUP JOIN retains the incoming row and adds nulls. If many rows in the lookup index match, LOOKUP JOIN adds one row per match.

In this example, we have two sample tables:

employees

birth_date emp_no first_name gender hire_date language

1955-10-04T00:00:00Z

10091

Amabile

M

1992-11-18T00:00:00Z

3

1964-10-18T00:00:00Z

10092

Valdiodio

F

1989-09-22T00:00:00Z

1

1964-06-11T00:00:00Z

10093

Sailaja

M

1996-11-05T00:00:00Z

3

1957-05-25T00:00:00Z

10094

Arumugam

F

1987-04-18T00:00:00Z

5

1965-01-03T00:00:00Z

10095

Hilari

M

1986-07-15T00:00:00Z

4

languagesnonunique_key

language_code language_name country

1

English

Canada

1

English

1

United Kingdom

1

English

United States of America

2

German

[Germany|Austria]

2

German

Switzerland

2

German

4

Quenya

5

Atlantis

[6|7]

Mv-Lang

Mv-Land

[7|8]

Mv-Lang2

Mv-Land2

Null-Lang

Null-Land

Null-Lang2

Null-Land2

Running the following query would provide the results shown below.

FROM employees
| EVAL language_code = emp_no % 10
| LOOKUP JOIN languages_lookup_non_unique_key ON language_code
| WHERE emp_no > 10090 AND emp_no < 10096
| SORT emp_no, country
| KEEP emp_no, language_code, language_name, country;
emp_no language_code language_name country

10091

1

English

Canada

10091

1

null

United Kingdom

10091

1

English

United States of America

10091

1

English

null

10092

2

German

[Germany, Austria]

10092

2

German

Switzerland

10092

2

German

null

10093

3

null

null

10094

4

Spanish

null

10095

5

null

France

LOOKUP JOIN does not guarantee the output to be in any particular order. If a certain order is required, users should use a SORT somewhere after the LOOKUP JOIN.

Prerequisites

edit

To use LOOKUP JOIN, the following requirements must be met:

  • Compatible data types: The join key and join field in the lookup index must have compatible data types. This means:

    • The data types must either be identical or be internally represented as the same type in ES|QL

    • Numeric types follow these compatibility rules:

      • short and byte are compatible with integer (all represented as int)
      • float, half_float, and scaled_float are compatible with double (all represented as double)
    • For text fields: You can only use text fields as the join key on the left-hand side of the join and only if they have a .keyword subfield

To obtain a join key with a compatible type, use a conversion function if needed.

For a complete list of supported data types and their internal representations, see the Supported Field Types documentation.

Limitations

edit

The following are the current limitations with LOOKUP JOIN

  • Indices in lookup mode are always single-sharded.
  • Cross cluster search is unsupported initially. Both source and lookup indices must be local.
  • Currently, only matching on equality is supported.
  • LOOKUP JOIN can only use a single match field and a single index. Wildcards, aliases, datemath, and datastreams are not supported.
  • The name of the match field in LOOKUP JOIN lu++_++idx ON match++_++field must match an existing field in the query. This may require renames or evals to achieve.
  • The query will circuit break if there are too many matching documents in the lookup index, or if the documents are too large. More precisely, LOOKUP JOIN works in batches of, normally, about 10,000 rows; a large amount of heap space is needed if the matching documents from the lookup index for a batch are multiple megabytes or larger. This is roughly the same as for ENRICH.
