GrimResource -  Microsoft Management Console for initial access and evasion

Overview

After Microsoft disabled office macros by default for internet-sourced documents, other infection vectors like JavaScript, MSI files, LNK objects, and ISOs have surged in popularity. However, these other techniques are scrutinized by defenders and have a high likelihood of detection. Mature attackers seek to leverage new and undisclosed infection vectors to gain access while evading defenses. A recent example involved DPRK actors using a new command execution technique in MSC files.

Elastic researchers have uncovered a new infection technique also leveraging MSC files, which we refer to as GrimResource. It allows attackers to gain full code execution in the context of mmc.exe after a user clicks on a specially crafted MSC file. A sample leveraging GrimResource was first uploaded to VirusTotal on June 6th.

Key takeaways

• Elastic Security researchers uncovered a novel, in-the-wild code execution technique leveraging specially crafted MSC files referred to as GrimResource
• GrimResource allows attackers to execute arbitrary code in Microsoft Management Console (mmc.exe) with minimal security warnings, ideal for gaining initial access and evading defenses
• Elastic is providing analysis of the technique and detection guidance so the community can protect themselves

Analysis

The key to the GrimResource technique is using an old XSS flaw present in the apds.dll library. By adding a reference to the vulnerable APDS resource in the appropriate StringTable section of a crafted MSC file, attackers can execute arbitrary javascript in the context of mmc.exe. Attackers can combine this technique with DotNetToJScript to gain arbitrary code execution.

At the time of writing, the sample identified in the wild had 0 static detections in VirusTotal.

The sample begins with a transformNode obfuscation technique, which was observed in recent but unrelated macro samples. This aids in evading ActiveX security warnings.

This leads to an obfuscated embedded VBScript, as reconstructed below:

The VBScript sets the target payload in a series of environment variables and then leverages the DotNetToJs technique to execute an embedded .NET loader. We named this component PASTALOADER and may release additional analysis on this specific tool in the future.

PASTALOADER retrieves the payload from environment variables set by the VBScript in the previous step:

Finally, PASTALOADER spawns a new instance of dllhost.exe and injects the payload into it. This is done in a deliberately stealthy manner using the DirtyCLR technique, function unhooking, and indirect syscalls. In this sample, the final payload is Cobalt Strike.

Detections

In this section, we will examine current behavior detections for this sample and present new, more precise ones aimed at the technique primitives.

Suspicious Execution via Microsoft Common Console

This detection was established prior to our discovery of this new execution technique. It was originally designed to identify a different method (which requires the user to click on the Taskpad after opening the MSC file) that exploits the same MSC file type to execute commands through the Console Taskpads command line attribute:

process where event.action == "start" and
 process.parent.executable : "?:\\Windows\\System32\\mmc.exe" and  process.parent.args : "*.msc" and
 not process.parent.args : ("?:\\Windows\\System32\\*.msc", "?:\\Windows\\SysWOW64\\*.msc", "?:\\Program files\\*.msc", "?:\\Program Files (x86)\\*.msc") and
 not process.executable :
              ("?:\\Windows\\System32\\mmc.exe",
               "?:\\Windows\\System32\\wermgr.exe",
               "?:\\Windows\\System32\\WerFault.exe",
               "?:\\Windows\\SysWOW64\\mmc.exe",
               "?:\\Program Files\\*.exe",
               "?:\\Program Files (x86)\\*.exe",
               "?:\\Windows\\System32\\spool\\drivers\\x64\\3\\*.EXE",
               "?:\\Program Files (x86)\\Microsoft\\Edge\\Application\\msedge.exe")

It triggers here because this sample opted to spawn and inject a sacrificial instance of dllhost.exe:

.NET COM object created in non-standard Windows Script Interpreter

The sample is using the DotNetToJScript technique, which triggers another detection looking for RWX memory allocation from .NET on behalf of a Windows Script Host (WSH) script engine (Jscript or Vbscript):

The following EQL rule will detect execution via the .NET loader:

api where
  not process.name : ("cscript.exe", "wscript.exe") and
  process.code_signature.trusted == true and
  process.code_signature.subject_name : "Microsoft*" and
  process.Ext.api.name == "VirtualAlloc" and
  process.Ext.api.parameters.allocation_type == "RESERVE" and
  process.Ext.api.parameters.protection == "RWX" and
  process.thread.Ext.call_stack_summary : (
    /* .NET is allocating executable memory on behalf of a WSH script engine
     * Note - this covers both .NET 2 and .NET 4 framework variants */
    "*|mscoree.dll|combase.dll|jscript.dll|*",
    "*|mscoree.dll|combase.dll|vbscript.dll|*",
    "*|mscoree.dll|combase.dll|jscript9.dll|*",
    "*|mscoree.dll|combase.dll|chakra.dll|*"
)

The following alert shows mmc.exe allocating RWX memory and the process.thread.Ext.call_stack_summary captures the origin of the allocation from vbscript.dll to clr.dll :

Script Execution via MMC Console File

The two previous detections were triggered by specific implementation choices to weaponize the GrimResource method (DotNetToJS and spawning a child process). These detections can be bypassed by using more OPSEC-safe alternatives.

Other behaviors that might initially seem suspicious — such as mmc.exe loading jscript.dll, vbscript.dll, and msxml3.dll — can be clarified compared to benign data. We can see that, except for vbscript.dll, these WSH engines are typically loaded by mmc.exe:

The core aspect of this method involves using apds.dll to execute Jscript via XSS. This behavior is evident in the mmc.exe Procmon output as a CreateFile operation (apds.dll is not loaded as a library):

We added the following detection using Elastic Defend file open events where the target file is apds.dll and the process.name is mmc.exe:

The following EQL rule will detect the execution of a script from the MMC console:

sequence by process.entity_id with maxspan=1m
 [process where event.action == "start" and
  process.executable : "?:\\Windows\\System32\\mmc.exe" and process.args : "*.msc"]
 [file where event.action == "open" and file.path : "?:\\Windows\\System32\\apds.dll"]

Windows Script Execution via MMC Console File

Another detection and forensic artifact is the creation of a temporary HTML file in the INetCache folder, named redirect[*] as a result of the APDS XSS redirection:

The following EQL correlation can be used to detect this behavior while also capturing the msc file path:

sequence by process.entity_id with maxspan=1m
 [process where event.action == "start" and
  process.executable : "?:\\Windows\\System32\\mmc.exe" and process.args : "*.msc"]
 [file where event.action in ("creation", "overwrite") and
  process.executable :  "?:\\Windows\\System32\\mmc.exe" and file.name : "redirect[?]" and
  file.path : "?:\\Users\\*\\AppData\\Local\\Microsoft\\Windows\\INetCache\\IE\\*\\redirect[?]"]

Alongside the provided behavior rules, the following YARA rule can be used to detect similar files:

rule Windows_GrimResource_MMC {
    meta:
        author = "Elastic Security"
        reference = "https://www.elastic.co/security-labs/GrimResource"
        reference_sample = "14bcb7196143fd2b800385e9b32cfacd837007b0face71a73b546b53310258bb"
        arch_context = "x86"
        scan_context = "file, memory"
        license = "Elastic License v2"
        os = "windows"
    strings:
        $xml = "<?xml"
        $a = "MMC_ConsoleFile"
        $b1 = "apds.dll"
        $b2 = "res://"
        $b3 = "javascript:eval("
        $b4 = ".loadXML("
    condition:
       $xml at 0 and $a and 2 of ($b*)
}

Conclusion

Attackers have developed a new technique to execute arbitrary code in Microsoft Management Console using crafted MSC files. Elastic’s existing out of the box coverage shows our defense-in-depth approach is effective even against novel threats like this. Defenders should leverage our detection guidance to protect themselves and their customers from this technique before it proliferates into commodity threat groups.

Observables

All observables are also available for download in both ECS and STIX formats.

The following observables were discussed in this research.
