Writing bool queries

edit

Writing bool queries

edit

Writing bool queries can grow verbose rather quickly when using the query DSL. For example, take a single bool query with two should clauses

var searchResults = this.Client.Search<Project>(s => s
    .Query(q => q
        .Bool(b => b
            .Should(
                bs => bs.Term(p => p.Name, "x"),
                bs => bs.Term(p => p.Name, "y")
            )
        )
    )
);

Now, imagine multiple nested bool queries; you’ll realise that this quickly becomes an exercise in hadouken indenting

hadouken indenting
Figure 2. hadouken indenting

Operator overloading

edit

For this reason, NEST introduces operator overloading so complex bool queries become easier to write. The overloaded operators are

We’ll demonstrate each with examples.

Binary || operator

edit

Using the overloaded binary || operator, a bool query with should clauses can be more succinctly expressed.

The previous example now becomes the following with the Fluent API

var firstSearchResponse = client.Search<Project>(s => s
    .Query(q => q
        .Term(p => p.Name, "x") || q
        .Term(p => p.Name, "y")
    )
);

and, with the the Object Initializer syntax

var secondSearchResponse = client.Search<Project>(new SearchRequest<Project>
{
    Query = new TermQuery { Field = Field<Project>(p => p.Name), Value = "x" } ||
            new TermQuery { Field = Field<Project>(p => p.Name), Value = "y" }
});

Both result in the following JSON query DSL

{
  "query": {
    "bool": {
      "should": [
        {
          "term": {
            "name": {
              "value": "x"
            }
          }
        },
        {
          "term": {
            "name": {
              "value": "y"
            }
          }
        }
      ]
    }
  }
}

Binary && operator

edit

The overloaded binary && operator can be used to combine queries together. When the queries to be combined don’t have any unary operators applied to them, the resulting query is a bool query with must clauses

var firstSearchResponse = client.Search<Project>(s => s
    .Query(q => q
        .Term(p => p.Name, "x") && q
        .Term(p => p.Name, "y")
    )
);

and, with the the Object Initializer syntax

var secondSearchResponse = client.Search<Project>(new SearchRequest<Project>
{
    Query = new TermQuery { Field = Field<Project>(p => p.Name), Value = "x" } &&
            new TermQuery { Field = Field<Project>(p => p.Name), Value = "y" }
});

Both result in the following JSON query DSL

{
  "query": {
    "bool": {
      "must": [
        {
          "term": {
            "name": {
              "value": "x"
            }
          }
        },
        {
          "term": {
            "name": {
              "value": "y"
            }
          }
        }
      ]
    }
  }
}

A naive implementation of operator overloading would rewrite

term && term && term

to

bool
|___must
   |___term
   |___bool
       |___must
           |___term
           |___term

As you can imagine this becomes unwieldy quite fast, the more complex a query becomes. NEST is smart enough to join the && queries together to form a single bool query

bool
|___must
   |___term
   |___term
   |___term

as demonstrated with the following

Assert(
    q => q.Query() && q.Query() && q.Query(),
    Query && Query && Query,
    c => c.Bool.Must.Should().HaveCount(3)
);

three queries && together using the Fluent API

three queries && together using Object Initialzer syntax

assert the resulting bool query in each case has 3 must clauses

Unary ! operator

edit

NEST also offers a shorthand notation for creating a bool query with a must_not clause using the unary ! operator

var firstSearchResponse = client.Search<Project>(s => s
    .Query(q => !q
        .Term(p => p.Name, "x")
    )
);

and, with the Object Initializer syntax

var secondSearchResponse = client.Search<Project>(new SearchRequest<Project>
{
    Query = !new TermQuery { Field = Field<Project>(p => p.Name), Value = "x" }
});

Both result in the following JSON query DSL

{
  "query": {
    "bool": {
      "must_not": [
        {
          "term": {
            "name": {
              "value": "x"
            }
          }
        }
      ]
    }
  }
}

Two queries marked with the unary ! operator can be combined with the && operator to form a single bool query with two must_not clauses

Assert(
    q => !q.Query() && !q.Query(),
    !Query && !Query,
    c => c.Bool.MustNot.Should().HaveCount(2));

two queries with ! operator applied, && together using the Fluent API

two queries with ! operator applied, && together using the Object Initializer syntax

assert the resulting bool query in each case has two must_not clauses

Unary + operator

edit

A query can be transformed into a bool query with a filter clause using the unary + operator

var firstSearchResponse = client.Search<Project>(s => s
    .Query(q => +q
        .Term(p => p.Name, "x")
    )
);

and, with the Object Initializer syntax

var secondSearchResponse = client.Search<Project>(new SearchRequest<Project>
{
    Query = +new TermQuery { Field = Field<Project>(p => p.Name), Value = "x" }
});

Both result in the following JSON query DSL

{
  "query": {
    "bool": {
      "filter": [
        {
          "term": {
            "name": {
              "value": "x"
            }
          }
        }
      ]
    }
  }
}

This runs the query in a filter context, which can be useful in improving performance where the relevancy score for the query is not required to affect the order of results.

Similarly to the unary ! operator, queries marked with the unary + operator can be combined with the && operator to form a single bool query with two filter clauses

Assert(
    q => +q.Query() && +q.Query(),
    +Query && +Query,
    c => c.Bool.Filter.Should().HaveCount(2));

Combining bool queries

edit

When combining multiple queries with the binary && operator where some or all queries have unary operators applied, NEST is still able to combine them to form a single bool query.

Take for example the following bool query

bool
|___must
|   |___term
|   |___term
|   |___term
|
|___must_not
   |___term

This can be constructed with NEST using

Assert(
    q => q.Query() && q.Query() && q.Query() && !q.Query(),
    Query && Query && Query && !Query,
    c=>
    {
        c.Bool.Must.Should().HaveCount(3);
        c.Bool.MustNot.Should().HaveCount(1);
    });

An even more complex example

term && term && term && !term && +term && +term

still only results in a single bool query with the following structure

bool
|___must
|   |___term
|   |___term
|   |___term
|
|___must_not
|   |___term
|
|___filter
   |___term
   |___term
Assert(
    q => q.Query() && q.Query() && q.Query() && !q.Query() && +q.Query() && +q.Query(),
    Query && Query && Query && !Query && +Query && +Query,
    c =>
    {
        c.Bool.Must.Should().HaveCount(3);
        c.Bool.MustNot.Should().HaveCount(1);
        c.Bool.Filter.Should().HaveCount(2);
    });

You can still mix and match actual bool queries with operator overloaded queries e.g

bool(must=term, term, term) && !term

This will still merge into a single bool query.

Assert(
    q => q.Bool(b => b.Must(mq => mq.Query(), mq => mq.Query(), mq => mq.Query())) && !q.Query(),
    new BoolQuery { Must = new QueryContainer[] { Query, Query, Query } } && !Query,
    c =>
    {
        c.Bool.Must.Should().HaveCount(3);
        c.Bool.MustNot.Should().HaveCount(1);
    });

Combining queries with || or should clauses

edit

As per the previous example, NEST will combine multiple should or || into a single bool query with should clauses, when it sees that the bool queries in play only consist of should clauses;

To summarize, this

term || term || term

becomes

bool
|___should
   |___term
   |___term
   |___term

However, the bool query does not quite follow the same boolean logic you expect from a programming language. That is

term1 && (term2 || term3 || term4)

does not become

bool
|___must
|   |___term1
|
|___should
   |___term2
   |___term3
   |___term4

Why is this? Well, when a bool query has only should clauses, at least one of them must match. However, when that bool query also has a must clause, the should clauses instead now act as a boost factor, meaning none of them have to match but if they do, the relevancy score for that document will be boosted and thus appear higher in the results. The semantics for how should clauses behave then changes based on the presence of the must clause.

So, relating this back to the previous example, you could get back results that only contain term1. This is clearly not what was intended when using operator overloading.

To aid with this, NEST rewrites the previous query as

bool
|___must
   |___term1
   |___bool
       |___should
           |___term2
           |___term3
           |___term4
Assert(
    q => q.Query() && (q.Query() || q.Query() || q.Query()),
    Query && (Query || Query || Query),
    c =>
    {
        c.Bool.Must.Should().HaveCount(2);
        var lastMustClause = (IQueryContainer)c.Bool.Must.Last();
        lastMustClause.Should().NotBeNull();
        lastMustClause.Bool.Should().NotBeNull();
        lastMustClause.Bool.Should.Should().HaveCount(3);
    });

Add parentheses to force evaluation order

Using should clauses as boost factors can be a really powerful construct when building search queries, and remember, you can mix and match an actual bool query with NEST’s operator overloading.

There is another subtle situation where NEST will not blindly merge two bool queries with only should clauses. Consider the following

bool(should=term1, term2, term3, term4, minimum_should_match=2) || term5 || term6

if NEST identified both sides of a binary || operation as only containing should clauses and joined them together, it would give a different meaning to the minimum_should_match parameter of the first bool query; rewriting this to a single bool with 5 should clauses would break the semantics of the original query because only matching on term5 or term6 should still be a hit.

Assert(
    q => q.Bool(b => b
        .Should(mq => mq.Query(), mq => mq.Query(), mq => mq.Query(), mq => mq.Query())
        .MinimumShouldMatch(2)
        )
         || !q.Query() || q.Query(),
    new BoolQuery
    {
        Should = new QueryContainer[] { Query, Query, Query, Query },
        MinimumShouldMatch = 2
    } || !Query || Query,
    c =>
    {
        c.Bool.Should.Should().HaveCount(3);
        var nestedBool = c.Bool.Should.First() as IQueryContainer;
        nestedBool.Bool.Should.Should().HaveCount(4);
    });

Locked bool queries

edit

NEST will not combine bool queries if any of the query metadata is set e.g if metadata such as boost or name are set, NEST will treat these as locked.

Here we demonstrate that two locked bool queries are not combined

Assert(
    q => q.Bool(b => b.Name("leftBool").Should(mq => mq.Query()))
         || q.Bool(b => b.Name("rightBool").Should(mq => mq.Query())),
    new BoolQuery { Name = "leftBool", Should = new QueryContainer[] { Query } }
    || new BoolQuery { Name = "rightBool", Should = new QueryContainer[] { Query } },
    c => AssertDoesNotJoinOntoLockedBool(c, "leftBool"));

neither are two bool queries where either right query is locked

Assert(
    q => q.Bool(b => b.Should(mq => mq.Query()))
         || q.Bool(b => b.Name("rightBool").Should(mq => mq.Query())),
    new BoolQuery { Should = new QueryContainer[] { Query } }
    || new BoolQuery { Name = "rightBool", Should = new QueryContainer[] { Query } },
    c => AssertDoesNotJoinOntoLockedBool(c, "rightBool"));

or the left query is locked

Assert(
    q => q.Bool(b => b.Name("leftBool").Should(mq => mq.Query()))
         || q.Bool(b => b.Should(mq => mq.Query())),
    new BoolQuery { Name = "leftBool", Should = new QueryContainer[] { Query } }
    || new BoolQuery { Should = new QueryContainer[] { Query } },
    c => AssertDoesNotJoinOntoLockedBool(c, "leftBool"));

Perfomance considerations

edit

If you have a requirement of combining many many queries using the bool dsl please take the following into account.

You can use bitwise assignments in a loop to combine many queries into a bigger bool.

In this example we are creating a single bool query with a 1000 must clauses using the &= assign operator.

var c = new QueryContainer();
var q = new TermQuery { Field = "x", Value = "x" };

for (var i = 0; i < 1000; i++)
{
    c &= q;
}
|     Median|     StdDev|       Gen 0|  Gen 1|  Gen 2|  Bytes Allocated/Op
|  1.8507 ms|  0.1878 ms|    1,793.00|  21.00|      -|        1.872.672,28

As you can see while still fast its causes a lot of allocations to happen because with each iteration we need to re evaluate the mergability of our bool query.

Since we already know the shape of our bool query in advance its much much faster to do this instead:

QueryContainer q = new TermQuery { Field = "x", Value = "x" };
var x = Enumerable.Range(0, 1000).Select(f => q).ToArray();
var boolQuery = new BoolQuery
{
    Must = x
};
|      Median|     StdDev|   Gen 0|  Gen 1|  Gen 2|  Bytes Allocated/Op
|  31.4610 us|  0.9495 us|  439.00|      -|      -|            7.912,95

The drop both in performance and allocations is tremendous!

If you assigning many bool queries prior to NEST 2.4.6 into a bigger bool query using an assignment loop, the client did not do a good job of flattening the result in the most optimal way and could cause a stackoverflow when doing ~2000 iterations. This only applied to bitwise assigning many bool queries, other queries were not affected.

Since NEST 2.4.6 you can combine as many bool queries as you’d like this way too. See PR #2335 on github for more information
