Suricata Integration
| Version | 2.24.0 (View all) |
| Compatible Kibana version(s) | 8.7.1 or higher 9.0.0 or higher |
| Supported Serverless project types What's this? |
Security Observability |
| Subscription level What's this? |
Basic |
| Level of support What's this? |
Elastic |
This integration is for Suricata. It reads the EVE JSON output file. The EVE output writes alerts, anomalies, metadata, file info and protocol specific records as JSON.
This module has been developed against Suricata v4.0.4, but is expected to work with other versions of Suricata.
Example
{
"@timestamp": "2018-07-05T19:01:09.820Z",
"agent": {
"ephemeral_id": "58adcb6e-5d0e-4822-98a4-8d93557f8f2e",
"id": "0a5c1566-c6fd-4e91-b96d-4083445a000e",
"name": "docker-fleet-agent",
"type": "filebeat",
"version": "8.9.0"
},
"data_stream": {
"dataset": "suricata.eve",
"namespace": "ep",
"type": "logs"
},
"destination": {
"address": "192.168.253.112",
"ip": "192.168.253.112",
"port": 22
},
"ecs": {
"version": "8.17.0"
},
"elastic_agent": {
"id": "0a5c1566-c6fd-4e91-b96d-4083445a000e",
"snapshot": false,
"version": "8.9.0"
},
"event": {
"agent_id_status": "verified",
"category": [
"network"
],
"created": "2023-08-08T15:09:13.171Z",
"dataset": "suricata.eve",
"ingested": "2023-08-08T15:09:14Z",
"kind": "event",
"type": [
"protocol"
]
},
"input": {
"type": "log"
},
"log": {
"file": {
"path": "/tmp/service_logs/eve-small.ndjson"
},
"offset": 0
},
"network": {
"community_id": "1:NLm1MbaBR6humQxEQI2Ai7h/XiI=",
"protocol": "ssh",
"transport": "tcp"
},
"related": {
"ip": [
"192.168.86.85",
"192.168.253.112"
]
},
"source": {
"address": "192.168.86.85",
"ip": "192.168.86.85",
"port": 55406
},
"suricata": {
"eve": {
"event_type": "ssh",
"flow_id": "298824096901438",
"in_iface": "en0",
"ssh": {
"client": {
"proto_version": "2.0",
"software_version": "OpenSSH_7.6"
},
"server": {
"proto_version": "2.0",
"software_version": "libssh_0.7.0"
}
}
}
},
"tags": [
"forwarded",
"suricata-eve"
]
}
Exported fields
| Field | Description | Type |
|---|---|---|
| @timestamp | Date/time when the event originated. This is the date/time extracted from the event, typically representing when the event was generated by the source. If the event source has no original timestamp, this value is typically populated by the first time the event was received by the pipeline. Required field for all events. | date |
| cloud.account.id | The cloud account or organization id used to identify different entities in a multi-tenant environment. Examples: AWS account id, Google Cloud ORG Id, or other unique identifier. | keyword |
| cloud.availability_zone | Availability zone in which this host, resource, or service is located. | keyword |
| cloud.image.id | Image ID for the cloud instance. | keyword |
| cloud.instance.id | Instance ID of the host machine. | keyword |
| cloud.instance.name | Instance name of the host machine. | keyword |
| cloud.machine.type | Machine type of the host machine. | keyword |
| cloud.project.id | The cloud project identifier. Examples: Google Cloud Project id, Azure Project id. | keyword |
| cloud.provider | Name of the cloud provider. Example values are aws, azure, gcp, or digitalocean. | keyword |
| cloud.region | Region in which this host, resource, or service is located. | keyword |
| container.id | Unique container id. | keyword |
| container.image.name | Name of the image the container was built on. | keyword |
| container.labels | Image labels. | object |
| container.name | Container name. | keyword |
| data_stream.dataset | The field can contain anything that makes sense to signify the source of the data. Examples include nginx.access, prometheus, endpoint etc. For data streams that otherwise fit, but that do not have dataset set we use the value "generic" for the dataset value. event.dataset should have the same value as data_stream.dataset. Beyond the Elasticsearch data stream naming criteria noted above, the dataset value has additional restrictions: * Must not contain - * No longer than 100 characters |
constant_keyword |
| data_stream.namespace | A user defined namespace. Namespaces are useful to allow grouping of data. Many users already organize their indices this way, and the data stream naming scheme now provides this best practice as a default. Many users will populate this field with default. If no value is used, it falls back to default. Beyond the Elasticsearch index naming criteria noted above, namespace value has the additional restrictions: * Must not contain - * No longer than 100 characters |
constant_keyword |
| data_stream.type | An overarching type for the data stream. Currently allowed values are "logs" and "metrics". We expect to also add "traces" and "synthetics" in the near future. | constant_keyword |
| destination.address | Some event destination addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the .address field. Then it should be duplicated to .ip or .domain, depending on which one it is. |
keyword |
| destination.as.number | Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet. | long |
| destination.as.organization.name | Organization name. | keyword |
| destination.as.organization.name.text | Multi-field of destination.as.organization.name. |
match_only_text |
| destination.bytes | Bytes sent from the destination to the source. | long |
| destination.domain | The domain name of the destination system. This value may be a host name, a fully qualified domain name, or another host naming format. The value may derive from the original event or be added from enrichment. | keyword |
| destination.geo.city_name | City name. | keyword |
| destination.geo.continent_name | Name of the continent. | keyword |
| destination.geo.country_iso_code | Country ISO code. | keyword |
| destination.geo.country_name | Country name. | keyword |
| destination.geo.location | Longitude and latitude. | geo_point |
| destination.geo.region_iso_code | Region ISO code. | keyword |
| destination.geo.region_name | Region name. | keyword |
| destination.ip | IP address of the destination (IPv4 or IPv6). | ip |
| destination.mac | MAC address of the destination. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| destination.packets | Packets sent from the destination to the source. | long |
| destination.port | Port of the destination. | long |
| dns.answers | An array containing an object for each answer section returned by the server. The main keys that should be present in these objects are defined by ECS. Records that have more information may contain more keys than what ECS defines. Not all DNS data sources give all details about DNS answers. At minimum, answer objects must contain the data key. If more information is available, map as much of it to ECS as possible, and add any additional fields to the answer objects as custom fields. |
group |
| dns.answers.class | The class of DNS data contained in this resource record. | keyword |
| dns.answers.data | The data describing the resource. The meaning of this data depends on the type and class of the resource record. | keyword |
| dns.answers.name | The domain name to which this resource record pertains. If a chain of CNAME is being resolved, each answer's name should be the one that corresponds with the answer's data. It should not simply be the original question.name repeated. |
keyword |
| dns.answers.ttl | The time interval in seconds that this resource record may be cached before it should be discarded. Zero values mean that the data should not be cached. | long |
| dns.answers.type | The type of data contained in this resource record. | keyword |
| dns.header_flags | Array of 2 letter DNS header flags. | keyword |
| dns.id | The DNS packet identifier assigned by the program that generated the query. The identifier is copied to the response. | keyword |
| dns.op_code | The DNS operation code that specifies the kind of query in the message. This value is set by the originator of a query and copied into the response. | keyword |
| dns.question.class | The class of records being queried. | keyword |
| dns.question.name | The name being queried. If the name field contains non-printable characters (below 32 or above 126), those characters should be represented as escaped base 10 integers (\DDD). Back slashes and quotes should be escaped. Tabs, carriage returns, and line feeds should be converted to \t, \r, and \n respectively. | keyword |
| dns.question.registered_domain | The highest registered domain, stripped of the subdomain. For example, the registered domain for "foo.example.com" is "example.com". This value can be determined precisely with a list like the public suffix list (https://publicsuffix.org). Trying to approximate this by simply taking the last two labels will not work well for TLDs such as "co.uk". | keyword |
| dns.question.subdomain | The subdomain is all of the labels under the registered_domain. If the domain has multiple levels of subdomain, such as "sub2.sub1.example.com", the subdomain field should contain "sub2.sub1", with no trailing period. | keyword |
| dns.question.top_level_domain | The effective top level domain (eTLD), also known as the domain suffix, is the last part of the domain name. For example, the top level domain for example.com is "com". This value can be determined precisely with a list like the public suffix list (https://publicsuffix.org). Trying to approximate this by simply taking the last label will not work well for effective TLDs such as "co.uk". | keyword |
| dns.question.type | The type of record being queried. | keyword |
| dns.resolved_ip | Array containing all IPs seen in answers.data. The answers array can be difficult to use, because of the variety of data formats it can contain. Extracting all IP addresses seen in there to dns.resolved_ip makes it possible to index them as IP addresses, and makes them easier to visualize and query for. |
ip |
| dns.response_code | The DNS response code. | keyword |
| dns.type | The type of DNS event captured, query or answer. If your source of DNS events only gives you DNS queries, you should only create dns events of type dns.type:query. If your source of DNS events gives you answers as well, you should create one event per query (optionally as soon as the query is seen). And a second event containing all query details as well as an array of answers. |
keyword |
| ecs.version | ECS version this event conforms to. ecs.version is a required field and must exist in all events. When querying across multiple indices -- which may conform to slightly different ECS versions -- this field lets integrations adjust to the schema version of the events. |
keyword |
| event.created | event.created contains the date/time when the event was first read by an agent, or by your pipeline. This field is distinct from @timestamp in that @timestamp typically contain the time extracted from the original event. In most situations, these two timestamps will be slightly different. The difference can be used to calculate the delay between your source generating an event, and the time when your agent first processed it. This can be used to monitor your agent's or pipeline's ability to keep up with your event source. In case the two timestamps are identical, @timestamp should be used. |
date |
| event.dataset | Event dataset | constant_keyword |
| event.duration | Duration of the event in nanoseconds. If event.start and event.end are known this value should be the difference between the end and start time. |
long |
| event.end | event.end contains the date when the event ended or when the activity was last observed. |
date |
| event.ingested | Timestamp when an event arrived in the central data store. This is different from @timestamp, which is when the event originally occurred. It's also different from event.created, which is meant to capture the first time an agent saw the event. In normal conditions, assuming no tampering, the timestamps should chronologically look like this: @timestamp < event.created < event.ingested. |
date |
| event.module | Event module | constant_keyword |
| event.original | Raw text message of entire event. Used to demonstrate log integrity or where the full log message (before splitting it up in multiple parts) may be required, e.g. for reindex. This field is not indexed and doc_values are disabled. It cannot be searched, but it can be retrieved from _source. If users wish to override this and index this field, please see Field data types in the Elasticsearch Reference. |
keyword |
| event.outcome | This is one of four ECS Categorization Fields, and indicates the lowest level in the ECS category hierarchy. event.outcome simply denotes whether the event represents a success or a failure from the perspective of the entity that produced the event. Note that when a single transaction is described in multiple events, each event may populate different values of event.outcome, according to their perspective. Also note that in the case of a compound event (a single event that contains multiple logical events), this field should be populated with the value that best captures the overall success or failure from the perspective of the event producer. Further note that not all events will have an associated outcome. For example, this field is generally not populated for metric events, events with event.type:info, or any events for which an outcome does not make logical sense. |
keyword |
| event.severity | The numeric severity of the event according to your event source. What the different severity values mean can be different between sources and use cases. It's up to the implementer to make sure severities are consistent across events from the same source. The Syslog severity belongs in log.syslog.severity.code. event.severity is meant to represent the severity according to the event source (e.g. firewall, IDS). If the event source does not publish its own severity, you may optionally copy the log.syslog.severity.code to event.severity. |
long |
| event.start | event.start contains the date when the event started or when the activity was first observed. |
date |
| file.name | Name of the file including the extension, without the directory. | keyword |
| file.path | Full path to the file, including the file name. It should include the drive letter, when appropriate. | keyword |
| file.path.text | Multi-field of file.path. |
match_only_text |
| file.size | File size in bytes. Only relevant when file.type is "file". |
long |
| host.architecture | Operating system architecture. | keyword |
| host.containerized | If the host is a container. | boolean |
| host.domain | Name of the domain of which the host is a member. For example, on Windows this could be the host's Active Directory domain or NetBIOS domain name. For Linux this could be the domain of the host's LDAP provider. | keyword |
| host.hostname | Hostname of the host. It normally contains what the hostname command returns on the host machine. |
keyword |
| host.id | Unique host id. As hostname is not always unique, use values that are meaningful in your environment. Example: The current usage of beat.name. |
keyword |
| host.ip | Host ip addresses. | ip |
| host.mac | Host MAC addresses. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| host.name | Name of the host. It can contain what hostname returns on Unix systems, the fully qualified domain name (FQDN), or a name specified by the user. The recommended value is the lowercase FQDN of the host. | keyword |
| host.os.build | OS build information. | keyword |
| host.os.codename | OS codename, if any. | keyword |
| host.os.family | OS family (such as redhat, debian, freebsd, windows). | keyword |
| host.os.kernel | Operating system kernel version as a raw string. | keyword |
| host.os.name | Operating system name, without the version. | keyword |
| host.os.name.text | Multi-field of host.os.name. |
match_only_text |
| host.os.platform | Operating system platform (such centos, ubuntu, windows). | keyword |
| host.os.version | Operating system version as a raw string. | keyword |
| host.type | Type of host. For Cloud providers this can be the machine type like t2.medium. If vm, this could be the container, for example, or other information meaningful in your environment. |
keyword |
| http.request.method | HTTP request method. The value should retain its casing from the original event. For example, GET, get, and GeT are all considered valid values for this field. |
keyword |
| http.request.referrer | Referrer for this HTTP request. | keyword |
| http.response.body.bytes | Size in bytes of the response body. | long |
| http.response.status_code | HTTP response status code. | long |
| input.type | Filebeat input type used to collect the log. | keyword |
| log.file.path | Full path to the log file this event came from, including the file name. It should include the drive letter, when appropriate. If the event wasn't read from a log file, do not populate this field. | keyword |
| log.offset | The file offset the reported line starts at. | long |
| message | For log events the message field contains the log message, optimized for viewing in a log viewer. For structured logs without an original message field, other fields can be concatenated to form a human-readable summary of the event. If multiple messages exist, they can be combined into one message. | match_only_text |
| network.bytes | Total bytes transferred in both directions. If source.bytes and destination.bytes are known, network.bytes is their sum. |
long |
| network.community_id | A hash of source and destination IPs and ports, as well as the protocol used in a communication. This is a tool-agnostic standard to identify flows. Learn more at https://github.com/corelight/community-id-spec. | keyword |
| network.packets | Total packets transferred in both directions. If source.packets and destination.packets are known, network.packets is their sum. |
long |
| network.protocol | In the OSI Model this would be the Application Layer protocol. For example, http, dns, or ssh. The field value must be normalized to lowercase for querying. |
keyword |
| network.transport | Same as network.iana_number, but instead using the Keyword name of the transport layer (udp, tcp, ipv6-icmp, etc.) The field value must be normalized to lowercase for querying. | keyword |
| observer.hostname | Hostname of the observer. | keyword |
| observer.ip | IP addresses of the observer. | ip |
| observer.mac | MAC addresses of the observer. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| observer.name | Custom name of the observer. This is a name that can be given to an observer. This can be helpful for example if multiple firewalls of the same model are used in an organization. If no custom name is needed, the field can be left empty. | keyword |
| observer.product | The product name of the observer. | keyword |
| observer.type | The type of the observer the data is coming from. There is no predefined list of observer types. Some examples are forwarder, firewall, ids, ips, proxy, poller, sensor, APM server. |
keyword |
| observer.vendor | Vendor name of the observer. | keyword |
| related.hash | All the hashes seen on your event. Populating this field, then using it to search for hashes can help in situations where you're unsure what the hash algorithm is (and therefore which key name to search). | keyword |
| related.hosts | All hostnames or other host identifiers seen on your event. Example identifiers include FQDNs, domain names, workstation names, or aliases. | keyword |
| related.ip | All of the IPs seen on your event. | ip |
| rule.category | A categorization value keyword used by the entity using the rule for detection of this event. | keyword |
| rule.id | A rule ID that is unique within the scope of an agent, observer, or other entity using the rule for detection of this event. | keyword |
| rule.name | The name of the rule or signature generating the event. | keyword |
| source.address | Some event source addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the .address field. Then it should be duplicated to .ip or .domain, depending on which one it is. |
keyword |
| source.as.number | Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet. | long |
| source.as.organization.name | Organization name. | keyword |
| source.as.organization.name.text | Multi-field of source.as.organization.name. |
match_only_text |
| source.bytes | Bytes sent from the source to the destination. | long |
| source.geo.city_name | City name. | keyword |
| source.geo.continent_name | Name of the continent. | keyword |
| source.geo.country_iso_code | Country ISO code. | keyword |
| source.geo.country_name | Country name. | keyword |
| source.geo.location | Longitude and latitude. | geo_point |
| source.geo.region_iso_code | Region ISO code. | keyword |
| source.geo.region_name | Region name. | keyword |
| source.ip | IP address of the source (IPv4 or IPv6). | ip |
| source.mac | MAC address of the source. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen. | keyword |
| source.packets | Packets sent from the source to the destination. | long |
| source.port | Port of the source. | long |
| suricata.eve.alert.affected_product | keyword | |
| suricata.eve.alert.attack_target | keyword | |
| suricata.eve.alert.capec_id | keyword | |
| suricata.eve.alert.category | keyword | |
| suricata.eve.alert.classtype | keyword | |
| suricata.eve.alert.created_at | date | |
| suricata.eve.alert.cve | keyword | |
| suricata.eve.alert.cvss_v2_base | keyword | |
| suricata.eve.alert.cvss_v2_temporal | keyword | |
| suricata.eve.alert.cvss_v3_base | keyword | |
| suricata.eve.alert.cvss_v3_temporal | keyword | |
| suricata.eve.alert.cwe_id | keyword | |
| suricata.eve.alert.deployment | keyword | |
| suricata.eve.alert.former_category | keyword | |
| suricata.eve.alert.gid | long | |
| suricata.eve.alert.hostile | keyword | |
| suricata.eve.alert.infected | keyword | |
| suricata.eve.alert.malware | keyword | |
| suricata.eve.alert.metadata | flattened | |
| suricata.eve.alert.mitre_tool_id | keyword | |
| suricata.eve.alert.performance_impact | keyword | |
| suricata.eve.alert.priority | keyword | |
| suricata.eve.alert.protocols | keyword | |
| suricata.eve.alert.rev | long | |
| suricata.eve.alert.rule_source | keyword | |
| suricata.eve.alert.sid | keyword | |
| suricata.eve.alert.signature | keyword | |
| suricata.eve.alert.signature_id | long | |
| suricata.eve.alert.signature_severity | keyword | |
| suricata.eve.alert.tag | keyword | |
| suricata.eve.alert.updated_at | date | |
| suricata.eve.app_proto_expected | keyword | |
| suricata.eve.app_proto_orig | keyword | |
| suricata.eve.app_proto_tc | keyword | |
| suricata.eve.app_proto_ts | keyword | |
| suricata.eve.dns.id | long | |
| suricata.eve.dns.rcode | keyword | |
| suricata.eve.dns.rdata | keyword | |
| suricata.eve.dns.rrname | keyword | |
| suricata.eve.dns.rrtype | keyword | |
| suricata.eve.dns.ttl | long | |
| suricata.eve.dns.tx_id | long | |
| suricata.eve.dns.type | keyword | |
| suricata.eve.email.status | keyword | |
| suricata.eve.event_type | keyword | |
| suricata.eve.fileinfo.gaps | boolean | |
| suricata.eve.fileinfo.md5 | keyword | |
| suricata.eve.fileinfo.sha1 | keyword | |
| suricata.eve.fileinfo.sha256 | keyword | |
| suricata.eve.fileinfo.state | keyword | |
| suricata.eve.fileinfo.stored | boolean | |
| suricata.eve.fileinfo.tx_id | long | |
| suricata.eve.flow.age | long | |
| suricata.eve.flow.alerted | boolean | |
| suricata.eve.flow.end | date | |
| suricata.eve.flow.reason | keyword | |
| suricata.eve.flow.state | keyword | |
| suricata.eve.flow_id | keyword | |
| suricata.eve.http.http_content_type | keyword | |
| suricata.eve.http.http_port | long | |
| suricata.eve.http.protocol | keyword | |
| suricata.eve.http.redirect | keyword | |
| suricata.eve.icmp_code | long | |
| suricata.eve.icmp_type | long | |
| suricata.eve.in_iface | keyword | |
| suricata.eve.pcap_cnt | long | |
| suricata.eve.smtp.helo | keyword | |
| suricata.eve.smtp.mail_from | keyword | |
| suricata.eve.smtp.rcpt_to | keyword | |
| suricata.eve.ssh.client.proto_version | keyword | |
| suricata.eve.ssh.client.software_version | keyword | |
| suricata.eve.ssh.server.proto_version | keyword | |
| suricata.eve.ssh.server.software_version | keyword | |
| suricata.eve.stats.app_layer.flow.dcerpc_tcp | long | |
| suricata.eve.stats.app_layer.flow.dcerpc_udp | long | |
| suricata.eve.stats.app_layer.flow.dns_tcp | long | |
| suricata.eve.stats.app_layer.flow.dns_udp | long | |
| suricata.eve.stats.app_layer.flow.failed_tcp | long | |
| suricata.eve.stats.app_layer.flow.failed_udp | long | |
| suricata.eve.stats.app_layer.flow.ftp | long | |
| suricata.eve.stats.app_layer.flow.http | long | |
| suricata.eve.stats.app_layer.flow.imap | long | |
| suricata.eve.stats.app_layer.flow.msn | long | |
| suricata.eve.stats.app_layer.flow.smb | long | |
| suricata.eve.stats.app_layer.flow.smtp | long | |
| suricata.eve.stats.app_layer.flow.ssh | long | |
| suricata.eve.stats.app_layer.flow.tls | long | |
| suricata.eve.stats.app_layer.tx.dcerpc_tcp | long | |
| suricata.eve.stats.app_layer.tx.dcerpc_udp | long | |
| suricata.eve.stats.app_layer.tx.dns_tcp | long | |
| suricata.eve.stats.app_layer.tx.dns_udp | long | |
| suricata.eve.stats.app_layer.tx.ftp | long | |
| suricata.eve.stats.app_layer.tx.http | long | |
| suricata.eve.stats.app_layer.tx.smb | long | |
| suricata.eve.stats.app_layer.tx.smtp | long | |
| suricata.eve.stats.app_layer.tx.ssh | long | |
| suricata.eve.stats.app_layer.tx.tls | long | |
| suricata.eve.stats.capture.kernel_drops | long | |
| suricata.eve.stats.capture.kernel_ifdrops | long | |
| suricata.eve.stats.capture.kernel_packets | long | |
| suricata.eve.stats.decoder.avg_pkt_size | long | |
| suricata.eve.stats.decoder.bytes | long | |
| suricata.eve.stats.decoder.dce.pkt_too_small | long | |
| suricata.eve.stats.decoder.erspan | long | |
| suricata.eve.stats.decoder.ethernet | long | |
| suricata.eve.stats.decoder.gre | long | |
| suricata.eve.stats.decoder.icmpv4 | long | |
| suricata.eve.stats.decoder.icmpv6 | long | |
| suricata.eve.stats.decoder.ieee8021ah | long | |
| suricata.eve.stats.decoder.invalid | long | |
| suricata.eve.stats.decoder.ipraw.invalid_ip_version | long | |
| suricata.eve.stats.decoder.ipv4 | long | |
| suricata.eve.stats.decoder.ipv4_in_ipv6 | long | |
| suricata.eve.stats.decoder.ipv6 | long | |
| suricata.eve.stats.decoder.ipv6_in_ipv6 | long | |
| suricata.eve.stats.decoder.ltnull.pkt_too_small | long | |
| suricata.eve.stats.decoder.ltnull.unsupported_type | long | |
| suricata.eve.stats.decoder.max_pkt_size | long | |
| suricata.eve.stats.decoder.mpls | long | |
| suricata.eve.stats.decoder.null | long | |
| suricata.eve.stats.decoder.pkts | long | |
| suricata.eve.stats.decoder.ppp | long | |
| suricata.eve.stats.decoder.pppoe | long | |
| suricata.eve.stats.decoder.raw | long | |
| suricata.eve.stats.decoder.sctp | long | |
| suricata.eve.stats.decoder.sll | long | |
| suricata.eve.stats.decoder.tcp | long | |
| suricata.eve.stats.decoder.teredo | long | |
| suricata.eve.stats.decoder.udp | long | |
| suricata.eve.stats.decoder.vlan | long | |
| suricata.eve.stats.decoder.vlan_qinq | long | |
| suricata.eve.stats.defrag.ipv4.fragments | long | |
| suricata.eve.stats.defrag.ipv4.reassembled | long | |
| suricata.eve.stats.defrag.ipv4.timeouts | long | |
| suricata.eve.stats.defrag.ipv6.fragments | long | |
| suricata.eve.stats.defrag.ipv6.reassembled | long | |
| suricata.eve.stats.defrag.ipv6.timeouts | long | |
| suricata.eve.stats.defrag.max_frag_hits | long | |
| suricata.eve.stats.detect.alert | long | |
| suricata.eve.stats.dns.memcap_global | long | |
| suricata.eve.stats.dns.memcap_state | long | |
| suricata.eve.stats.dns.memuse | long | |
| suricata.eve.stats.file_store.open_files | long | |
| suricata.eve.stats.flow.emerg_mode_entered | long | |
| suricata.eve.stats.flow.emerg_mode_over | long | |
| suricata.eve.stats.flow.icmpv4 | long | |
| suricata.eve.stats.flow.icmpv6 | long | |
| suricata.eve.stats.flow.memcap | long | |
| suricata.eve.stats.flow.memuse | long | |
| suricata.eve.stats.flow.spare | long | |
| suricata.eve.stats.flow.tcp | long | |
| suricata.eve.stats.flow.tcp_reuse | long | |
| suricata.eve.stats.flow.udp | long | |
| suricata.eve.stats.flow_mgr.bypassed_pruned | long | |
| suricata.eve.stats.flow_mgr.closed_pruned | long | |
| suricata.eve.stats.flow_mgr.est_pruned | long | |
| suricata.eve.stats.flow_mgr.flows_checked | long | |
| suricata.eve.stats.flow_mgr.flows_notimeout | long | |
| suricata.eve.stats.flow_mgr.flows_removed | long | |
| suricata.eve.stats.flow_mgr.flows_timeout | long | |
| suricata.eve.stats.flow_mgr.flows_timeout_inuse | long | |
| suricata.eve.stats.flow_mgr.new_pruned | long | |
| suricata.eve.stats.flow_mgr.rows_busy | long | |
| suricata.eve.stats.flow_mgr.rows_checked | long | |
| suricata.eve.stats.flow_mgr.rows_empty | long | |
| suricata.eve.stats.flow_mgr.rows_maxlen | long | |
| suricata.eve.stats.flow_mgr.rows_skipped | long | |
| suricata.eve.stats.http.memcap | long | |
| suricata.eve.stats.http.memuse | long | |
| suricata.eve.stats.tcp.insert_data_normal_fail | long | |
| suricata.eve.stats.tcp.insert_data_overlap_fail | long | |
| suricata.eve.stats.tcp.insert_list_fail | long | |
| suricata.eve.stats.tcp.invalid_checksum | long | |
| suricata.eve.stats.tcp.memuse | long | |
| suricata.eve.stats.tcp.no_flow | long | |
| suricata.eve.stats.tcp.overlap | long | |
| suricata.eve.stats.tcp.overlap_diff_data | long | |
| suricata.eve.stats.tcp.pseudo | long | |
| suricata.eve.stats.tcp.pseudo_failed | long | |
| suricata.eve.stats.tcp.reassembly_gap | long | |
| suricata.eve.stats.tcp.reassembly_memuse | long | |
| suricata.eve.stats.tcp.rst | long | |
| suricata.eve.stats.tcp.segment_memcap_drop | long | |
| suricata.eve.stats.tcp.sessions | long | |
| suricata.eve.stats.tcp.ssn_memcap_drop | long | |
| suricata.eve.stats.tcp.stream_depth_reached | long | |
| suricata.eve.stats.tcp.syn | long | |
| suricata.eve.stats.tcp.synack | long | |
| suricata.eve.stats.uptime | long | |
| suricata.eve.tcp.ack | boolean | |
| suricata.eve.tcp.fin | boolean | |
| suricata.eve.tcp.psh | boolean | |
| suricata.eve.tcp.rst | boolean | |
| suricata.eve.tcp.state | keyword | |
| suricata.eve.tcp.syn | boolean | |
| suricata.eve.tcp.tcp_flags | keyword | |
| suricata.eve.tcp.tcp_flags_tc | keyword | |
| suricata.eve.tcp.tcp_flags_ts | keyword | |
| suricata.eve.tls.fingerprint | keyword | |
| suricata.eve.tls.issuerdn | keyword | |
| suricata.eve.tls.ja3.hash | keyword | |
| suricata.eve.tls.ja3.string | keyword | |
| suricata.eve.tls.ja3s.hash | keyword | |
| suricata.eve.tls.ja3s.string | keyword | |
| suricata.eve.tls.notafter | date | |
| suricata.eve.tls.notbefore | date | |
| suricata.eve.tls.serial | keyword | |
| suricata.eve.tls.session_resumed | boolean | |
| suricata.eve.tls.sni | keyword | |
| suricata.eve.tls.subject | keyword | |
| suricata.eve.tls.version | keyword | |
| suricata.eve.tx_id | long | |
| tags | List of keywords used to tag each event. | keyword |
| threat.framework | Name of the threat framework used to further categorize and classify the tactic and technique of the reported threat. Framework classification can be provided by detecting systems, evaluated at ingest time, or retrospectively tagged to events. | keyword |
| threat.tactic.id | The id of tactic used by this threat. You can use a MITRE ATT&CK® tactic, for example. (ex. https://attack.mitre.org/tactics/TA0002/ ) | keyword |
| threat.tactic.name | Name of the type of tactic used by this threat. You can use a MITRE ATT&CK® tactic, for example. (ex. https://attack.mitre.org/tactics/TA0002/) | keyword |
| threat.technique.id | The id of technique used by this threat. You can use a MITRE ATT&CK® technique, for example. (ex. https://attack.mitre.org/techniques/T1059/) | keyword |
| threat.technique.name | The name of technique used by this threat. You can use a MITRE ATT&CK® technique, for example. (ex. https://attack.mitre.org/techniques/T1059/) | keyword |
| threat.technique.name.text | Multi-field of threat.technique.name. |
match_only_text |
| tls.client.ja3 | A hash that identifies clients based on how they perform an SSL/TLS handshake. | keyword |
| tls.client.server_name | Also called an SNI, this tells the server which hostname to which the client is attempting to connect to. When this value is available, it should get copied to destination.domain. |
keyword |
| tls.resumed | Boolean flag indicating if this TLS connection was resumed from an existing TLS negotiation. | boolean |
| tls.server.hash.sha1 | Certificate fingerprint using the SHA1 digest of DER-encoded version of certificate offered by the server. For consistency with other hash values, this value should be formatted as an uppercase hash. | keyword |
| tls.server.issuer | Subject of the issuer of the x.509 certificate presented by the server. | keyword |
| tls.server.ja3s | A hash that identifies servers based on how they perform an SSL/TLS handshake. | keyword |
| tls.server.not_after | Timestamp indicating when server certificate is no longer considered valid. | date |
| tls.server.not_before | Timestamp indicating when server certificate is first considered valid. | date |
| tls.server.subject | Subject of the x.509 certificate presented by the server. | keyword |
| tls.server.x509.issuer.common_name | List of common name (CN) of issuing certificate authority. | keyword |
| tls.server.x509.issuer.country | List of country (C) codes | keyword |
| tls.server.x509.issuer.locality | List of locality names (L) | keyword |
| tls.server.x509.issuer.organization | List of organizations (O) of issuing certificate authority. | keyword |
| tls.server.x509.issuer.organizational_unit | List of organizational units (OU) of issuing certificate authority. | keyword |
| tls.server.x509.issuer.state_or_province | List of state or province names (ST, S, or P) | keyword |
| tls.server.x509.not_after | Time at which the certificate is no longer considered valid. | date |
| tls.server.x509.not_before | Time at which the certificate is first considered valid. | date |
| tls.server.x509.serial_number | Unique serial number issued by the certificate authority. For consistency, this should be encoded in base 16 and formatted without colons and uppercase characters. | keyword |
| tls.server.x509.subject.common_name | List of common names (CN) of subject. | keyword |
| tls.server.x509.subject.country | List of country (C) code | keyword |
| tls.server.x509.subject.locality | List of locality names (L) | keyword |
| tls.server.x509.subject.organization | List of organizations (O) of subject. | keyword |
| tls.server.x509.subject.organizational_unit | List of organizational units (OU) of subject. | keyword |
| tls.server.x509.subject.state_or_province | List of state or province names (ST, S, or P) | keyword |
| tls.version | Numeric part of the version parsed from the original string. | keyword |
| tls.version_protocol | Normalized lowercase protocol name parsed from original string. | keyword |
| url.domain | Domain of the url, such as "www.elastic.co". In some cases a URL may refer to an IP and/or port directly, without a domain name. In this case, the IP address would go to the domain field. If the URL contains a literal IPv6 address enclosed by [ and ] (IETF RFC 2732), the [ and ] characters should also be captured in the domain field. |
keyword |
| url.original | Unmodified original url as seen in the event source. Note that in network monitoring, the observed URL may be a full URL, whereas in access logs, the URL is often just represented as a path. This field is meant to represent the URL as it was observed, complete or not. | wildcard |
| url.original.text | Multi-field of url.original. |
match_only_text |
| url.path | Path of the request, such as "/search". | wildcard |
| url.query | The query field describes the query string of the request, such as "q=elasticsearch". The ? is excluded from the query string. If a URL contains no ?, there is no query field. If there is a ? but no query, the query field exists with an empty string. The exists query can be used to differentiate between the two cases. |
keyword |
| user_agent.device.name | Name of the device. | keyword |
| user_agent.name | Name of the user agent. | keyword |
| user_agent.original | Unparsed user_agent string. | keyword |
| user_agent.original.text | Multi-field of user_agent.original. |
match_only_text |
| user_agent.os.full | Operating system name, including the version or code name. | keyword |
| user_agent.os.full.text | Multi-field of user_agent.os.full. |
match_only_text |
| user_agent.os.name | Operating system name, without the version. | keyword |
| user_agent.os.name.text | Multi-field of user_agent.os.name. |
match_only_text |
| user_agent.os.version | Operating system version as a raw string. | keyword |
| user_agent.version | Version of the user agent. | keyword |
Changelog
| Version | Details | Kibana version(s) |
|---|---|---|
| 2.24.0 | Enhancement (View pull request) Support stack version 9.0. |
8.7.1 or higher 9.0.0 or higher |
| 2.23.0 | Enhancement (View pull request) Allow the usage of deprecated log input and support for stack 9.0 |
8.7.1 or higher |
| 2.22.0 | Enhancement (View pull request) ECS version updated to 8.17.0. |
8.7.1 or higher |
| 2.21.4 | Bug fix (View pull request) Fix parsing of extra commas in TLS subject and issuer fields. |
8.7.1 or higher |
| 2.21.3 | Bug fix (View pull request) Use triple-brace Mustache templating when referencing variables in ingest pipelines. |
8.7.1 or higher |
| 2.21.2 | Bug fix (View pull request) Handle unset TLS data fields |
8.7.1 or higher |
| 2.21.1 | Bug fix (View pull request) Fix TLS version parsing for SSLv2 kind of value format. |
8.7.1 or higher |
| 2.21.0 | Enhancement (View pull request) Update package-spec to 3.0.3. |
8.7.1 or higher |
| 2.20.2 | Enhancement (View pull request) Changed owners |
8.7.1 or higher |
| 2.20.1 | Bug fix (View pull request) Fix exclude_files pattern. |
8.7.1 or higher |
| 2.20.0 | Enhancement (View pull request) ECS version updated to 8.11.0. |
8.7.1 or higher |
| 2.19.0 | Enhancement (View pull request) Improve 'event.original' check to avoid errors if set. |
8.7.1 or higher |
| 2.18.1 | Bug fix (View pull request) Fix mapping of group fields |
8.7.1 or higher |
| 2.18.0 | Enhancement (View pull request) Populate observer.* fields if "forwarded" in tags |
8.7.1 or higher |
| 2.17.1 | Enhancement (View pull request) Refer to the ECS definition for all fields that exist in ECS. |
8.7.1 or higher |
| 2.17.0 | Enhancement (View pull request) ECS version updated to 8.10.0. |
8.7.1 or higher |
| 2.16.0 | Enhancement (View pull request) The format_version in the package manifest changed from 2.11.0 to 3.0.0. Removed dotted YAML keys from package manifest. Added 'owner.type: elastic' to package manifest. |
8.7.1 or higher |
| 2.15.0 | Enhancement (View pull request) Add tags.yml file so that integration's dashboards and saved searches are tagged with "Security Solution" and displayed in the Security Solution UI. |
8.7.1 or higher |
| 2.14.0 | Enhancement (View pull request) Use ECS imported rather than local definitions. |
8.7.1 or higher |
| 2.13.0 | Enhancement (View pull request) Use dynamic field definitions. |
8.7.1 or higher |
| 2.12.0 | Enhancement (View pull request) Update package-spec to 2.9.0. |
8.7.1 or higher |
| 2.11.0 | Enhancement (View pull request) Update package to ECS 8.9.0. |
8.7.1 or higher |
| 2.10.0 | Enhancement (View pull request) Convert dashboards to Lens |
8.7.1 or higher |
| 2.9.0 | Enhancement (View pull request) Ensure event.kind is correctly set for pipeline errors. |
8.1.0 or higher |
| 2.8.0 | Enhancement (View pull request) Update package to ECS 8.8.0. |
8.1.0 or higher |
| 2.7.0 | Enhancement (View pull request) Update package to ECS 8.7.0. |
8.1.0 or higher |
| 2.6.1 | Enhancement (View pull request) Added categories and/or subcategories. |
8.1.0 or higher |
| 2.6.0 | Enhancement (View pull request) Update package to ECS 8.6.0. |
8.1.0 or higher |
| 2.5.3 | Enhancement (View pull request) Migrate the visualizations to by value in dashboards to minimize the saved object clutter and reduce time to load |
8.1.0 or higher |
| 2.5.2 | Bug fix (View pull request) Remove duplicate fields. |
8.0.0 or higher |
| 2.5.1 | Bug fix (View pull request) Defensive copy of parameter lists |
8.0.0 or higher |
| 2.5.0 | Enhancement (View pull request) Update package to ECS 8.5.0. |
8.0.0 or higher |
| 2.4.2 | Enhancement (View pull request) Use ECS geo.location definition. |
8.0.0 or higher |
| 2.4.1 | Enhancement (View pull request) Remove unused visualizations |
8.0.0 or higher |
| 2.4.0 | Enhancement (View pull request) Update package to ECS 8.4.0 |
8.0.0 or higher |
| 2.3.1 | Enhancement (View pull request) Update package name and description to align with standard wording |
8.0.0 or higher |
| 2.3.0 | Enhancement (View pull request) Add Server Name Indication to related.hosts for TLS events. Bug fix (View pull request) Render host.mac hardware addresses according to ECS. |
8.0.0 or higher |
| 2.2.0 | Enhancement (View pull request) Update package to ECS 8.3.0. |
8.0.0 or higher |
| 2.1.0 | Enhancement (View pull request) Add JA3/JA3S to related.hash |
8.0.0 or higher |
| 2.0.0 | Enhancement (View pull request) Migrate map visualisation from tile_map to map object |
8.0.0 or higher |
| 1.7.0 | Enhancement (View pull request) Update to ECS 8.2 |
7.14.0 or higher 8.0.0 or higher |
| 1.6.1 | Enhancement (View pull request) Add documentation for multi-fields |
7.14.0 or higher 8.0.0 or higher |
| 1.6.0 | Enhancement (View pull request) Add network.protocol support for krb5, smtp, snmp, and ikev2. |
7.14.0 or higher 8.0.0 or higher |
| 1.5.0 | Bug fix (View pull request) Set destination.ip in events. Enhancement (View pull request) Format MAC addresses per ECS and RFC 7042. |
7.14.0 or higher 8.0.0 or higher |
| 1.4.0 | Enhancement (View pull request) Update to ECS 8.0 |
— |
| 1.3.2 | Bug fix (View pull request) Regenerate test files using the new GeoIP database |
7.14.0 or higher 8.0.0 or higher |
| 1.3.1 | Bug fix (View pull request) Change test public IPs to the supported subset |
— |
| 1.3.0 | Enhancement (View pull request) Add 8.0.0 version constraint |
7.14.0 or higher 8.0.0 or higher |
| 1.2.3 | Enhancement (View pull request) Uniform with guidelines |
7.14.0 or higher |
| 1.2.2 | Enhancement (View pull request) Update Title and Description. |
— |
| 1.2.1 | Bug fix (View pull request) Fix logic that checks for the 'forwarded' tag |
— |
| 1.2.0 | Enhancement (View pull request) Update to ECS 1.12.0 |
7.14.0 or higher |
| 1.1.3 | Enhancement (View pull request) Convert to generated ECS fields |
— |
| 1.1.2 | Enhancement (View pull request) update to ECS 1.11.0 |
— |
| 1.1.1 | Enhancement (View pull request) Escape special characters in docs |
— |
| 1.1.0 | Enhancement (View pull request) Update integration description |
— |
| 1.0.1 | Bug fix (View pull request) Fixes improper date fields and metadata field issues. |
— |
| 1.0.0 | Enhancement (View pull request) make GA Enhancement (View pull request) Set "event.module" and "event.dataset" |
7.14.0 or higher |
| 0.6.3 | Enhancement (View pull request) Use wildcard field type. |
— |
| 0.6.2 | Enhancement (View pull request) Modify event.original and update ECS version to 1.10.0 |
— |
| 0.6.1 | Enhancement (View pull request) Make event.original optional |
— |
| 0.6.0 | Enhancement (View pull request) Move edge processing to ingest pipelines |
— |
| 0.5.2 | Enhancement (View pull request) update to ECS 1.9.0 |
— |
| 0.5.1 | Bug fix (View pull request) Change kibana.version constraint to be more conservative. |
— |
| 0.0.1 | Enhancement (View pull request) initial release |
— |
